8.4KN
|
|
||||||||||||||||||||||||||||||||||||||||||||||||
| SWIVEL HEAD |
 |
|||
| Drive System | Hydraulic motor driven, with 2-speed gear | |||
| Spindle Bore | 145 mm | |||
| Spindle Speed | high | 0 ～ 90 r.p.m | ||
| low | 0 ～ 45 r.p.m | |||
| Spindle Torque | high | 425 kg-m(40 r.p.m) | ||
| low | 850 kg-m(20 r.p.m) | |||
| Rod Chuck System | Hydraulic | |||
| FEEDER | ||||
| Drive System | Hydraulic motor driven and chain feed | |||
| Feeding Stroke | 6,000 mm | |||
| Feeding Pressure | 3,000 kg (MAX) | |||
| Feed Speed | 0 - 4 m/min | |||
| Leader Slide device | 800 mm | |||
| Leader Swing device | 5 degree, Right & Left | |||
| Hydraulic capacity | 210 kg/cm2 - 130 L/min (Rotation) | |||
| Hydraulic capacity | 110 kg/cm2 - 46 L/min (Feed) | |||
| BASE MACHINE | ||||
| Crawler Capacity | 0.16 m3 Class , (51.5 PS/2,400 rpm) | |||
| WEIGHT | ||||
| Approx. Gross Weight | 7,500 kg | |||
| Dimensions: | 8,740 mm (L) x 2,000 mm (W) x 2,500 mm (H) | |||
| OPTIONAL EQUIPMENT | ||||
| Feed Step System | Setting flexibly (CJG/JSG) | |||
| Flow meter | Quantity of cement-milk | |||
| Working Recorder |
Process records of depth, rotation, quantity |
|||
